Long Pole กก
Pinpointer

About | Price | Warranty | Video | Views
MP-40W
waterproof
MP-40U
underwater
40 inch Metalprobe is an indispensable tool to:
  1. Speed target recovery
  2. Prevent digging large holes
  3. Accurately find small objects
  4. Underwater or Underground hunting
  5. Identify multiple objects in near proximity
  6. Search in tight interior areas such as Sandy beach and Stream or smalll river
  • Constant tone over the targets
Feature
  • Power source: 1 x 9 volt block alkaline or rechargeable 9V 600 mAh Li battery
  • Alarm indicator: LED+ Buzzer or LED + Vibration alarm (in handle)
  • Power indicator: Green LED
  • Search sensor: Detection area that is the entire length, circumference and tip of the detection probe
  • Minimum Battery Life ( normal working ):
    Rechargeable Li-ion 600mAh: 80 Hours
  • Power Operation: On ⇒ LED + Buzzer alarm ⇒ LED + Vibration alarm ⇒ LED torch light ⇒ Off
  • Case construction: High impact ABS
  • switch button can send

    SOS distress signal light found 4 KM away at night

  • Rugged pushbutton latching switch Ingress protection
    (dust and moisture protection and resistance): IP67
  • Warranty: 24 months Limited ( parts and labor )
It is very effective in easily detecting even the smallest of ( grain size 1-2 mm ) metallic objects in a wide variety of hunting conditions.

An LED flashlight assists in dark and low light conditions Adjustable Brightness.

Sensitivity can be adjusted by fingers ( adjustments of potentiometer voltage ) you can detecting dim. 0.05 inch ( 2mm )gold grain.

It can be used underwater 30-100 feet and it also can be used on the ground for metal material ranging from highly mineralized ground to saltwater-saturated sand.

Low battery power warning, the red LED will flashed and you will hear short "Bip! Bip!" sound.

Specification Long ( gold ) Hunting Metal Probe
Operating Temperatures: -30°F(-35°C) to 150°F(68°C)
Underwater Distance: 5~30 feet 30~100 feet 100~300 feet 300~500 feet UP
Operating Frequency: 105kHz
Indicators:
1. Buzzer alarm ( waterproof model: Min sound output dB 70 )
2. Silent / Vibration ( Motor rpm 15000 )
3. LED Alert Lights Green: Power ON
Red: Alarm condition
Controls: Power switch ( ON - Buzzer - Vibration - LED flashlight - OFF )
Battery: Li-ion  rechargeable battery 580mAh provides up to 80 hours on each 2 hour recharge
Dimensions: Length: 15 inch ( 40 cm ), 40 inch ( 100 cm ) 60 inch ( 150 cm )
Diameter: Probe end: 1.3 cm - 1.7 cm ( 0.5 - 0.66 inches )
Handle End: 4.5 cm (1.80 inches)
Thickness: 0.12 inch (3mm) tapered to 0.08 inch ( 2 mm )
Scan Area: 3.9" ( 100 mm ) long; 360° plus tip
Unit Net Weight: 16 inch: 200g, 40 inch: 400g ( without  Battery ) 60 inch: 600g ( without Battery )
Package: 15 inch 50PCs/Carton, 40 inch 30PCs/Carton, 60 inch 20PCs/Carton
Gross Weight: 22KG,   25KG, 20KG ( with all accessory )
Model Length
inch
LED
alarm
Buzzer
alarm
Vibra
alarm
One
body
Flashlight
brightness
sensitivity - manual tuning / threshold adjustment Waterproof
Underwater
buzzer
( dB )
0.6 inch gold coin 0.1 inch gold grain
MP-40W 40 × adjustable 1.2" tip  1.5" side 0.03" tip  0.05" side can work in the rain 75
MP-40U 40 adjustable 1.5" tip  2.0" side 0.05" tip  0.08" side underwater 30 feet 35


Testing Card Board:
40 inch long range pinpointer MP-40 decrease the time of target recovery tremendously and helping you dig more good grain in a shorter period of time underground 40 feet and with less digging, it is realy happy treasure hunting work both underground and underwater.


  1. The LED light - Red color warning when gold to be found
  2. The speaker provides a clear audible sound whenever metal is detected.
  3. Vibrator motor also activates when a metallic target has been detected.

Waterproof Control board



Underwater Control board
Operating Instructions - sensitivity adjusted manually  is  can detecting more deeper and accuracy.Before detection, sensitivity must be tuned for maximum sensitivity-critical point, to do so, Please press On/off button to power on and follow the instruction bellow:
  1. Switch the detector on by pressing the power button while holding the detector away from any metallic objects. To avoid canceling out the target, do not turn on the Metal Probe while it is adjacent to the target. The Green Power LED will illuminate and one brief audio beep will occur, indicating the Metal Probe is ready for use.
  2. All metals will be detected including ferrous and non-ferrous.
  3. You should use Metal Probe to precisely locate your metallic target.
    1. As you move the tip of the Metal Probe closer to the target object, the detector's vibrations or audible beeps will be warning.
    2. Side-Scan recovery: One of the key features of the Metal Probe is its side-scan detection ability.
      This feature allows you to quickly search a large area. Hold the Metal Probe on its side, flat against the target and quickly scan back and forth.
      Once the general location of the target is known, use the tip of the Metal Probe to precisely locate the target.
    3. Water recoveries: Another key feature of the Metal Detector Metal Probe detector is that it is fully waterproof
      This allows you to search in rain and wet areas without concern of damaging your metal probe.
    4. Shoal searches: Long Pole Metal probe can hunting small grain in water and you need not jump into the river before confirm the metal has been buried the waterbed
      Use the side-scan technique to quickly cover large areas and use the pinpointing tip to precisely locate the target.
  4. The white LED Light will illuminate when the Metal Probe is on and this light will remain on until the power button is pressed again to switch off the unit. This mini flashlight feature is useful when operating in low light situations.
Specification: Angle: 5~60°
Material: Optical Grade PMMA
Working Temp.: -35~+90°C
multiple optical precision molding machines and automated production processes, making the LED lens has strict quality requirements form designing to finishing, for the sake of achieving and perfect optical effect.
It is applicable to Solar lamp, Underground lamp, Underwater lamp, Wall lights, Spotlights, LED lighting and other LED applications.

Luminous Intensity
20000 - 25000 MCD
Brightness Adjustable
Top LED flashlight bright
distance 5-8 meters at night
Battery Charging:
When the battery becomes low, the detector will sound an alternating dual-tone alarm and alarm LED light will be dark. This sound indicates that the detector's 9V battery should be charged as soon as possible by unscrewing the battery cover and use Solar Charger or Adaptor only 2 hours the battery will full of power and hand-tighten the battery cover.
  • Cleaning Your LMP
    1. To remove dried dirt, mud or other debris from your LMP, simply hand-clean it with soap and water and a soft cloth.
    2. Rinse with running water.
    3. Do not use any type of abrasive or chemical cleaners which could scratch or erode the surface of your detector.

  • Note:
    Do not affix metallic labels (or any material that might cause the detector to alarm) to the detection area of the LMP.
    Doing so might cause an imbalance within the detection field and thereby reduce scanning effectiveness.

    Attention: Air, water, sand or mud are different media, so you need adjust sensitivity when change media eg. ↓
    1. When you detecting in mud: put probe 1 inch in mud and adjust Sensitivity before hunting
    2. When you detecting in sand: put probe 1 inch in sand and adjust Sensitivity before hunting
    3. When you detecting in water: put probe 1 inch in water and adjust Sensitivity before hunting
  1. Underwater 30 feet and can over 300 feet  ( inside switch )

  2. Buzzer alarm ( waterproof model: Min sound output dB75 / underwater dB35 )

  3. Vibration alarm ( Sensitive feeling, Motor rpm 15000 )

  4. Top LED torch, Bright distance 5-8 meters and brightness adjustable
    ( with Protection cover Material: Optical Grade PMMA )

  5. Waterproof Nylon Holster ( can be put into salt water )
    Luxury PU leather holster or Real leather holster ( option )

  6. ABS Telescopic handle - can help you to search in deep Narrow hole from 1 meter to 5 meters ( option )

  7. 9V Li battery 600mAh can support normal operation over 80 hours ( normal operating )

  8. The one body ABS Probe detecting stick is hard enough to dig in any condition ( can withstand 15 kg torque from the side and impact 100 kg form top and 200 kg from back )
MP-40U
